In 2026, AMD Machines quoted a plastic staking station for a manufacturer in Mexico at $150,000–$190,000 for the station alone and $160,000–$200,000 with shipping and five days of commissioning. The quote proposes one station that secures two plates to an armrest by staking six ABS plastic poles, four by ultrasonic staking and two by heat staking, on a two-position rotary index table.
Buyers rarely see what a staking machine costs, so this case study breaks the budgetary AMD Machines quote down line by line for US manufacturers. It is based on the quote and describes what was quoted, not results from a running machine. The customer isn't named, and prices are shown as ranges.
A plastic staking station is a machine that melts and reforms plastic posts protruding through a mating part into rivet-like heads that hold it without screws, clips or adhesive; AMD Machines quoted one in 2026 using ultrasonic and heat staking.
The quote calls this machine a welding machine and the job "riveting"; the process, sometimes called plastic riveting, is staking. For the plastic joining systems AMD Machines builds, see ultrasonic and thermal joining systems.
The AMD Machines quote at a glance:
| Quote item | In the AMD Machines quote |
|---|---|
| Part | Armrest carrying a PA6 plastic plate and a metal plate |
| Machine | One staking station with a Weiss two-position rotary index table |
| Staking points | Six ABS plastic poles: four ultrasonic, two heat staked |
| Design cycle time | About 45 seconds per part, from simulation |
| Power | 440 V, three-phase, 60 Hz, with 24 VDC controls |
| Annual volume and shifts | Not stated |
| Total with shipping and commissioning | $160,000–$200,000, in US dollars, VAT not included |
| Lead time | 16–18 weeks, depending on AMD's workload |
What Is in a Combined Ultrasonic and Heat Staking Station?
The combined ultrasonic and heat staking station in a 2026 AMD Machines quote stakes six poles with two processes on one mechanism: four Herrmann VE35 actuator units for ultrasonic staking and a PID-controlled heat-staking system with two heads. The quote specifies a welded steel frame, a Weiss two-position rotary index table and Siemens controls.
| System | Equipment in the AMD Machines quote |
|---|---|
| Ultrasonic generators | Two Herrmann AMG 1200 MX Ultraplast generators with EtherNet/IP |
| Ultrasonic staking units | Four Herrmann VE35 actuator units with Herrmann KHS35 converters and CPM sonotrodes at 35 kHz |
| Heat staking | Two heat-staking generators with PID temperature control driving two heads on two pneumatic cylinders; two tips per head, with heating cartridge and thermocouple kits |
| Index table | Weiss two-position rotary index table with a variable frequency drive |
| Fixture | Custom fixturing on an aluminum index plate, with a pneumatic fixture lifter |
| PLC and HMI | Siemens S7-1200 PLC with its modules in the main cabinet; Siemens MTP700 Unified Basic HMI in a small secondary cabinet |
| Sensors and I/O | IO-Link master and slaves; part-present sensors; magnetic cylinder sensors; HID proximity card reader |
| Pneumatics | Filter-regulator-lubricator unit, valve manifold and cylinders; SMC listed as preferred |
| Frame and guarding | Welded steel frame with base plate and leveling pads; aluminum-profile guarding with panels; polycarbonate window; safety door for maintenance and service, with interlocks |
| Status | Multicolor light tower; station lamp |
How Much Does a Plastic Staking Station Cost?
In a 2026 AMD Machines quote, a combined ultrasonic and heat staking station costs $150,000–$190,000 FOB AMD's plant in Querétaro, Mexico, and $160,000–$200,000 with shipping and five days of commissioning. The budgetary quote was in US dollars, before VAT, and valid for 30 days.
| Line in the AMD Machines quote | Price range |
|---|---|
| Staking station, FOB AMD's plant in Querétaro, Mexico | $150,000–$190,000 |
| Shipping with insurance (optional) | Under $5,000 |
| Commissioning, 5 days | $6,000–$8,000 |
| Total with shipping and commissioning | $160,000–$200,000 |
The AMD Machines quote prices shipping with insurance as an optional line from AMD's plant; for a US plant, ask for freight to your site to be quoted.
How Does This Two-Process Staking Station Compare With a Standalone Ultrasonic Station?
In the 2026 AMD Machines quote, the two-process staking station, at $150,000–$190,000 for the station alone, starts where the $75,000 to $150,000 range AMD Machines publishes for a standalone ultrasonic welding station ends; it carries two staking processes, six staking points and an index table.
The AMD Machines thermal joining systems page says: "A standalone ultrasonic welding station with servo actuation, process monitoring, and safety guarding typically runs $75,000 to $150,000 depending on complexity. Multi-station systems with robotic loading, vision inspection, and leak testing can range from $250,000 to $750,000+." The quoted station sits below that multi-station range and includes no robotic loading, vision inspection or leak test.
The AMD Machines guide to what automation costs says simple single-station cells ("one press-fit, one screwdriving operation, basic verification") "start from ~$100K." The quoted two-process station sits well above that floor.
What Are the Payment Terms for a Staking Station?
In the 2026 AMD Machines staking station quote, payment is split across four milestones: 40% with a purchase order, 30% at design approval, 20% at approval in AMD's plant and 10% at approval in the buyer's facility.
What Moves the Price of a Staking Station?
Five choices move the price of a staking station most: the number of staking points, the process for each pole, part presentation, component brands and validation. The AMD Machines quote sets them as follows:
| Cost driver | In the AMD Machines quote | How it moves the price |
|---|---|---|
| Staking points | Six poles: four ultrasonic, each on its own Herrmann VE35 unit, two heat staked | Added poles usually add tooling |
| Process per pole | Ultrasonic for the four poles holding the PA6 plate; heat staking for the two poles holding the metal plate | Two processes mean two sets of tooling, each with its own controls; one process usually costs less |
| Part presentation | Two-position index table with a lifting fixture | Usually costs more than a fixed nest, and gives a load position away from the tooling |
| Component brands | Siemens (PLC), Herrmann (ultrasonics), Weiss (index table) and SMC (pneumatics) listed as preferred | Preferred or required brands fix part of the bill of materials |
| Validation | An empty test, a 300-part production lot or as required, and a checklist | Requirements beyond the standard run-off can add cost |
Why Does One Staking Station Use Both Ultrasonic and Heat Staking?
In the 2026 AMD Machines quote, one staking station uses both processes because AMD's engineering team assigns one joining method to each of the armrest's two plates: ultrasonic staking for the four poles holding the PA6 plastic plate, and PID-controlled heat staking for the two holding the metal plate. The quote does not say why the metal plate's poles are heat staked rather than staked ultrasonically.
The AMD Machines quote mounts the ultrasonic and heat-staking tooling on one mechanism, which a pneumatic cylinder moves to a single process position over one fixture, so the part is located once for all six poles.
Why Put a Staking Station on a Two-Position Rotary Index Table?
A two-position rotary index table lets a staking station be loaded away from its process position, clear of the heated tips and vibrating sonotrodes. In the 2026 AMD Machines quote, parts are loaded at one position of the Weiss table and staked at the other, behind guarding with a polycarbonate window.
Can a Staking Station Use Your Plant's PLC, Safety and Pneumatics Brands?
Yes. While preparing its 2026 staking station quote, AMD Machines asked the buyer for its PLC, safety and pneumatics standards so the machine would be quoted to them, and offered AMD's standard components otherwise. Asking that question first avoids requoting a machine after the plant's maintenance team reviews it.
How Does a Staking Station Work, Step by Step?
From the mechanisms the 2026 AMD Machines quote describes, the staking station cycle runs in six steps: load the armrest into the fixture, index it to the process position, lift the fixture, advance the combined staking mechanism, stake four poles ultrasonically and two by heat staking, then index back and unload. AMD Machines based the design cycle of about 45 seconds per part, or 1.33 parts a minute, on simulation results.
- Load. The armrest, with both plates in place, is loaded into a custom fixture on the table's aluminum plate at the load position.
- Index. The Weiss table carries the part to the process position.
- Lift. A pneumatic cylinder lifts the fixture from below to position the part.
- Advance. A pneumatic cylinder moves the combined staking mechanism into the process position.
- Stake. The four poles holding the PA6 plastic plate are staked ultrasonically, and the two poles holding the metal plate are heat staked. The quote states neither the order of the two processes nor whether they run at the same time.
- Return and unload. The table indexes back to the load position, and the finished part is unloaded.
What Safety Equipment Does a Staking Station Need?
The 2026 AMD Machines staking station quote safeguards the station with safety light curtains, aluminum-profile guarding with a polycarbonate window, two safety magnetic interlocks on the service doors, two emergency stops (one at the worktable, one at the secondary cabinet) and a safety relay.
For a US plant, write into your request for quote that the control panel be built to UL 508A, the electrical equipment to NFPA 79 and the safeguarding assessed against the ANSI B11 machine safety standards, so the price includes them from the start.
What Does a Staking Station Quote Include and Leave Out?
The AMD Machines staking station quote includes design, manufacturing, debugging, programming, validation at AMD's plant, documentation and a 12-month warranty. Under the quote, the buyer would cover VAT, part data and samples, changes after an order and, without the shipping option, freight.
| Item | In the AMD Machines quote |
|---|---|
| Design, manufacturing, debugging and programming | Included |
| Validation at AMD's plant | Included: an empty test, a production lot of 300 parts or as required, and a checklist |
| Manuals and documentation package | Included: two digital copies and one printed copy |
| Warranty on parts AMD builds | 12 months, valid once the machine is paid for |
| Warranty on bought-out components | Their suppliers' warranties |
| Commissioning, 5 days | Separate priced line |
| Freight without the shipping option | Buyer, since the station is priced FOB AMD's plant |
| VAT | Buyer; not included |
| Part drawings, 2D and 3D files, sample parts | Buyer |
| Changes after an order is placed | Quoted separately |
| Specific validation requirements beyond the standard run-off | May cost extra |
How Long Does It Take to Build a Staking Station?
AMD Machines quoted a lead time of 16 to 18 weeks for the combined ultrasonic and heat staking station, depending on AMD's workload when an order is placed. The quote places build and validation at AMD's plant in Querétaro, Mexico, before the optional shipping and the five days of commissioning.
AMD Machines delivers simple machines in as little as 6 weeks and complex systems in 24–26 weeks, vs. 40–42 weeks typical for overseas builders. The quoted 16 to 18 weeks sits between those ranges. The AMD Machines guide to custom automation lead times explains what sets the schedule.
What Should You Send to Get a Staking Station Quoted?
To get a staking station quoted, send AMD Machines your part and component data, sample parts, and your production and plant requirements:
| What to send | Why AMD Machines needs it |
|---|---|
| 3D models and 2D drawings of the part and every captured component, with each pole marked | Sets the pole count, fixture and tooling |
| Material of the part and of each captured component | Guides the process for each pole |
| Sample parts and components | Trials to confirm each pole's process |
| Target cycle time, annual volume and shifts | Sizes the station |
| Loading method: a person at the station or an automated line | Sets the part presentation |
| Plant voltage, phase and frequency, and the electrical and safety standards to build to | Sets the electrical and safety design |
| Fastener standard, inch or metric | Sets the screws AMD Machines specifies; the 2026 quote calls for metric |
| Preferred brands for PLC, HMI, ultrasonics, pneumatics and safety | Fixes part of the bill of materials |
| Validation, documentation, freight and commissioning needs | Sets the scope lines of the quote |
If the staking station will sit in a line, the AMD Machines page on custom automated assembly machines covers multi-station rotary, linear and robotic machines that choose a joining method per station.
Staking Station FAQ
What is the difference between ultrasonic staking and heat staking?
Ultrasonic staking melts a plastic post with high-frequency vibration from a sonotrode, 35 kHz in a 2026 AMD Machines quote, while heat staking melts it with heated tips in direct contact, held at temperature by a controller. Both reform the post into a head that captures the mating component. For process detail, see the AMD Machines guides to ultrasonic joining of plastics and the heat staking process.
Can one machine run both ultrasonic and heat staking?
Yes. In a 2026 AMD Machines quote, one staking station mounts the ultrasonic and the heat-staking tooling on one mechanism and runs both processes at a single process position, so the part is located once.
What cycle time does a staking station run?
About 45 seconds per part, or 1.33 parts a minute, in a 2026 AMD Machines quote for a six-pole staking station, based on simulation results. Cycle time depends on the pole count, the process for each pole and how the part is loaded, so AMD Machines sizes each station to your part and target cycle time.
If you're budgeting a staking machine, send your part and components to request a staking station quote, and AMD Machines will tell you which process fits each pole and what the station costs.
